10.25 Inches for Lexus CT200h CT 2014-2021 Car Radio Multimedia Player Wireless CarPlay Android Auto Upgrade Android Touch Screen

Compatible Models:
Lexus CT200h CT 2014-2021

Advantage

1. The screen can work independently to ensure the normal function of the original car.

2. Support original car rear view and 360 camera.

3. Independent control of brightness, automatic switching of day and night mode.

4. The original car with CarPlay&Carlife models supports OEM touch.

5. IPS wide viewing angle high-brightness high-resolution digital LED screen (1920X720);

6. Sapphire anti-glare capacitive touch screen, no reflection under strong light, close to the OEM screen.

7. The design is strictly in accordance with the definition of the OEM screen interface, the screen part is completely plugged, and no circuit is modified to ensure the cleanliness and safety of the screen!

8. The screen reserves an independent high-resolution LVDS interface, which is convenient for adding high-definition equipment.

Screen Part Configuration

• Resolution: 1920X720(10.25”and 12.3”)

• Touch Function: Support(If original car screen have touch function, it will support both OEM and Android touch).

• Screen work type: Can work independently

• Touch screen type: Sapphire anti-glare

• OEM Function: Support

• OEM CAM and 360 CAM: Support

• Screen brightness adjustment: Support

• Style: Original car style

• Install: Plug and play

• Speed and time display: Support

• Screen start time: Same OEM

Hardware Configuration

• CPU MODEL: RK3399 PX6

• 6core1.8G(2coreA724coreA53) Hexa-Core process: Dual-core ARM Cortex-A72 1.8GHz and Quad-core ARM Cortex-A53 1.4GHz.

• TF Card :Maximum support 64GB (Product not include TF Card)

• AV IN: DTV

• HDMI OUT:Support 720P (For connect rear seat screen and headrest. )

• Navi Sound: Add small speakers. If not listen radio at the same time, the navi sound from original car speakers.

• Camera: Front/Left/Rear/Right(guideline and radar )/AHD INPUT

• USBPorts: USB0-OTG wired carplay/ USB1：U disk playback and ADAS/ USB2: U disk playback and 3G/4G dongle.

Special Function

• MCU and APP Update:Connect WIFI Using Internetonline upgrade

• Cold start Time:40 seconds

• Hot Start:6 seconds

• Sleep:Yes(Loop 5 times)

• Sleep memory: Remember Last APP in parking

• Installation Method: Plug and Play

Switching Method

• Switch Mode:Use the steering wheel MODE button to cycle through.

• Switch Mode1:In radio or other screen select AUX automatically switch android.

• Switch Mode2:Use original car radio or other screen: Long press the off phone button for 3 seconds to switch Android.

• Switch Mode3:Use panel media button to cycle through Switch.

• Switch Mode4:Use original car voice button to call open AUX, automatically switch.

• Switch Mode5:Use the meter to select AUX to enter automatically.

Body Multimedia Control

• Microphone:Use original car

• Steering Wheel：Support up and down song, Vol.

• Forced Reset:: MODE （Long press 5 seconds）

• Original Car BT in Android:Caller ID 10 seconds to automatically return to Android current.

• A/C DISP: Support in the Android interface display.

• Speed Control:Add CAM 20 km Effective.

Optional Function

• Radio Module: For Japanese version cars.

• ADAS: Record and take photos, track deviation and reminder of the vehicle ahead, etc.

• 360 CAM: Support AHD to add input

• 4G network card: Provide network data and WIFI signal.
